Product Dimensions 6"h x 29.88"w x 19.63"d
Air quality is a top concern for today’s families. The Broan series, with its superior capture efficiency, is the ideal solution. This model is sure to win over even the most demanding users with its innovative design, advanced technology, and unmatched performance.Read More
Captur™ exclusive system that provides faster smoke & odor removal
Hidden 2-speed rocker control
Two 50 W GU10 halogen bulbs (not included) provide warm and direct lighting (2-level lighting)
Two high efficiency micro filters, easy to clean
Performant blower
HVI certified
Quiet range hood offering a sound level of 1.5 sones at low speed
Use charcoal filter HPF24 for a non-ducted installation
ADA compliant, remote operation is possible using a standard UL approved momentary wall switch. Click here for wiring instructions.
General Specs | |
| Width (in.) | 29.88 |
| Height (in.) | 6 |
| Duct Size (in.) | 3.25 x 10 |
| Depth (in.) | 19.63 |
| Collection | Glacier |
| Color | Stainless Steel |
| Appliance Fit Width (cm.) | 76 |
| Manufacturer Warranty | 1 Year |
| Color Finish Name | Stainless Steel |
| Range Hood Type | Under Cabinet |
| ADA Compliant | Yes |
| ENERGY STAR Certified | No |
| Appliance Fit Width (in.) | 30 |
| Maximum CFM | 250 |
| Bulb Type | Halogen |
| Grease Filter Type | Aluminum Mesh |
| Sones Rating | 1.5 - 5.0 |
| Fan Speed Options | 2 |
| Height Above Cooktop | 18 - 24 |
| Width (cm) | 75.9 |
| Height (cm.) | 15.24 |
| Depth (cm.) | 49.86 |
| Height Above Cooktop Centimeter | 45.72cm - 60.96cm |
| Voltage | 120 |
| Amp | 1.4 |
| Frequency | 60 |
| Range Hood Features | Ductless Capable, Heat Sensor, Charcoal Filter |
| Noise Level (Sones) | Standard - (High) |
| Ventilation Type | Ducted |
More Information: | |
| Boost Mode | No |
| Category | Standard $$ |
| Control Type | Hidden 2-speed Rocker Control |
| Ducting Size | 3-1/4 in X 10 in or 7 in Round |
| Filter Type | High Efficiency Micro Filters |
| Heat Sentry™ Automatic Heat Sensor | Yes |
| Lighting Intensity | 2 |
| Lighting Type | Two 50 W GU10 halogen bulbs (not included) |
| Optional Control | No |
| Series | Glacier |
| Ventilation Speeds | 2 |
